For the production and supply of Printed Circuit Boards we use approved by us subcontractors, which offer excellent value for money and best delivery times. All printed circuit boards are delivered after in-circuit test.
Technological options for bare circuit boards:
- Minimum bus structure – 200 μm
- Minimum distance – 180 μm by base material FR4 with 18 μm Cu
- Minimum metal opening – 0,4mm
- Number of layers – up to 12 layers
- Material: FR4, FR2, Polyimide Flexible, CEM1, CEM3, AlCu, Rogers.
- Thickness of 0,2 to 3,2 мм depending on the customer’s requirements
- Thickness of the copper coating – 18 μm, 35 μm, 70 μm, 105 μm, 140 μm, 175 μm
- Final coating – Lead-free HAL, Lead HAL, Chemical Ni/Au, Chemical tin, Passivation (OSP)
- Protective mask – Photo mask, epoxy mask, UV mask in different colours
Information needed for processing of inquiries in PRIMA-TECH-PRO regarding the design and delivery of printed circuit boards:
- Complete Gerber files in mm or mils.
- Drill files in any format.
- Number of circuit boards in a lot.
- Text file with full description of the printed circuit board – Material and thickness, Copper coating thickness, Final coating, Protective mask colour, White printing, Electrical test
